Standard
Specifications
Flange Interface Thread: 1-1/16-12UN
Inlet Diameter: 7/8 In (22 mm)
Weight: .07 lb (32 g)
Overall Height: 1-1/8 In ( 29 mm)
Standoff Above Flange: 3/8 In (10 mm)
Wrench Hex Size: 1-3/8 In
Material: Anodized Aluminum
Available Variations
| Product # | Feature | Opening Range (Psig) | Opening Range (kPa) | Minimum Close (Psig) | Minimum Close (kPa) |
|---|---|---|---|---|---|
| A-53047 | with cap | 2.5-2.7 Psig | 17-19 kPa | 2.1 Psig | 14 kPa |
| A-53047-1 | with O-ring | 2.5-2.7 Psig | 17-19 kPa | 2.1 Psig | 14 kPa |
| A-53001 | with cap | 4.1-4.6 Psig | 28-32 kPa | 3.5 Psig | 24 kPa |
| A-53001-1 | with O-ring | 4.1-4.6 Psig | 28-32 kPa | 3.5 Psig | 24 kPa |
